Carson CS-30DS MG 30 kg/cm 8.4 V waterproof servo

Carson CS-30DS MG 30 kg/cm 8.4 V waterproof servo

CARSON 500502061

The CARSON CS-30DS servo is a powerful (up to 34.6kg/cm at 8.4V) and fast (up to 0.13sec/60° at 8.4V) standard-size servo, designed for use in wet environments (autumn/winter). The robust metal gear train ensures a long service life for the servo. Ideal for use in models requiring a powerful steering servo that may be exposed to damp conditions.

Standard-sized, splash-proof servo with high torque.

Specifications:

• Supply voltage: 4.8V–6V
• Torque at 6V: ~30kg.cm
• Torque at 8.4V: 34.6kg.cm
• Speed at 8.4V: 0.13 sec/60°
• Dimensions: 40.5x20.2x40.3mm
• Gear teeth: 25T
• Coreless motor
• Metal gear train
• Ball bearing mounted
• Suitable for damp environments
• Weight: 62g
• Connector type: Graupner/JR
