Waterproof bow thruster Ø16mm

Bow thruster Ø 16mm waterproof

Ref Raboesch 108.02

These very powerful bow thrusters come fully mounted and equipped with a 7.2-volt Power 400 electric motor. The propulsion is carried out via a flat propeller that pushes the water through the nozzles and the whole works as a pump. This structure is very strong and stable and requires practically no maintenance. The pump body and extender ducts are made of ABS. The motor is connected using a G seal and an O-ring that prevent water from entering and therefore allow the bow thruster to be mounted both vertically and horizontally. The motor and pump body cover are easily removable. The cover is provided with an O-ring that makes the assembly waterproof.

Mandatory use of a drive to control the engine, which avoids a too sharp start that could damage the thruster.

Do not run the thruster dry which would damage the seal.

For more technical information: see the dimensional diagram and technical data of the engine.

Inner diameter: Ø16mm

Power 400 electric motor (7.2v):
RPM 17.000 – off load.
Intensity : 0.5 Ampere – Blocking intensity: 20 Amps.
Yield: 78%.
Engine axis: 2.3 x 12 mm.
Weight: 72 Grams.
