Robbe NAVY Control 540 R 40A 6V-24V ESC

Robbe NAVY Control 540 R 40A 6V-24V Electronic Speed Controller

Robbe 8616

Replaces the well-known "Roxxy Navy 700 40A" offered by Multiplex

Special marine electronic speed controller, for power supplies up to 24V, particularly suited for the motors of large models.

Housing made entirely of anodized aluminum for optimal heat dissipation.

Technical Specifications:

• Functions: forward – stop – reverse
• Supply voltage: 6V to 24V (6 to 18 NiMH cells, 6V to 24V lead-acid, or 2S to 6S lithium)
• Maximum current: 40A (50A peak)
• Pulse frequency: 1 kHz
• Dimensions: 75x67x39mm
• Weight: 231g
• This ESC does not include a "BEC" system (a separate receiver power supply is required)
• Receiver connection: standard Futaba servo plug
• Motor connection: 10 AWG wires supplied without connectors
• Battery connection: 10 AWG wires supplied without connector

Features:

• FET: Power-MOS field-effect transistors
• OPTO: Galvanic isolation of the receiver and motor circuits to prevent reception problems caused by motor interference
• POR: Power-on protection preventing unintended motor startup
• TP: Protection against excessive temperatures
• PCO: Shutdown in case of low voltage
• RXF: RX filter; shuts down the ESC when no signal is received from the transmitter or when the transmitter signal is faulty
• LED: Display of operating and programming functions
• WP: Protection against water splashes
