RC switch module 4x350mA

RC switch module 4x350mA

Module for remote control of lights or low-power functions (small radar). Four outputs can be switched independently with a single radio control channel.

Module can be powered by the receiver or by an external power source up to 14 volts. Output voltage = input voltage.

The module enables up to 4 outputs to be independently switched on and off using a channel controlled by a 3-position switch or a radio control stick.

Each of the four outputs can be independently switched on or off with a short or long press on either side of the switch.

Easy connection via screw terminals, no soldering required!

Technical data :

• 4 independent outputs (max. 350mA each)
• Module supply voltage: from receiver (BEC) or external power supply (6V to 14V)
• LED supply voltage: same as module supply voltage
• Max. switching current 350mA/output (equivalent to 17 full-power LEDs per output)

Requires patch cord for connection to receiver (see "accessories" below).
