HITEC D625MW digital servo 10kg/7,4V - 0,13s

Servo HITEC D625MW digital 10kg/7,4V - 0,13s

HITEC 116625

The ultra-fast HS D-625MW HITEC D-Series servos offer the highest resolution on the market today. The best response and programming possibilities are achieved thanks to the 32-bit MCU and 12-bit ADC technology.

The 'D' series includes HITEC servos for both conventional (4.8/6V) and HV (8.4V) voltages. So you can power them as you wish.

The HS-625MW Digital servo is fully programmable and offers good durability thanks to its robust all-steel gears and two ball bearings on the output shaft, which are particularly suitable where low backlash and high positioning accuracy are important.

The long service life and uniquely designed transmission make it one of the most reliable and efficient servos on the market.

Features :

• Servo type: standard
• Special features: wide voltage range / digital
• Servo motor type: coreless
• Equipment: steel
• Operating voltage in V: 4.8-8.4 V
• Operating time s/60° at 4.8 volts: 0.20
• Operating time s/60° at 6.0 volts: 0.15
• Operating time s/60° at 7.4 volts: 0.13
• Torque in kg.cm at 4.8 volts: 6.3
• Torque at kg.cm at 6.0 volts: 8.8
• Torque at kg.cm at 7.4 volts: 10
• Toothing: 25T
• Ball bearing: yes
• Sealed: no

Dimensions:

• Width: 20mm
• Height: 37mm
• Length: 40mm
• Weight: 60g
