Fr-sky Taranis QX7 ACCESS Black 2.4Ghz (EU-LBT) Transmitter with TECNIMODEL configuration

Radio Fr-sky Taranis QX7S ACCESS Black 2.4Ghz (EU-LBT)

With special TECNIMODEL configuration for trucks and boats.

The TARANIS QX7 radio is equipped with the 2.4 Ghz ACCST transmission system which guarantees excellent signal transmission.
Delivered as a basic 16-channel radio, this radio can control an additional 16 channels by simply adding an additional transmission module to be clipped at the back of the transmitter.

This radio controller comes without battery and receiver. Choose receivers Fr-sky EU-LBT Version v2.1.x.

The power of OpenTX: Its internal system based on an open-source system "OpenTX" allows a very advanced use of the radio controller whatever its use.
TECNIMODEL configuration: We have customized the configuration of the internal program to make it more accessible to users of multifunctional models (Model boats and radio controlled trucks) without the need to dive into a complex configuration. However, all the power of the system remains available for advanced users.
The transmitter FRSKY Taranis QX7S is delivered by TECNIMODEL completely in French (internal system, announcement messages (if optional microSD card), adapted custom configuration, specific instructions and memories of preloaded models).

Specific configuration by TECNIMODEL:

• Configuration and instructions entirely in French.
• The gimbals are all centered, without notching (notching is however available by modifying an internal setting of the case).
• Pre-recorded model memories facilitate the immediate use of the radio controller. These models are also used as a basis for possible additional settings or the creation of other model memories.
• Model memory for radio controlled trucks with MFC-01 and MFC-03: these models allow direct use of Tamiya multifunction units without special configuration and without the need for the use of trims for extended functions.
• Memory Models for sinple boats or for models boats with two motors.

Command elements:

• 2 ball bearing mounted gimbals, both gimbals are configured to be centered. It is possible to restore the notching on the handle of your choice.
• 2 rotating potentiometers (one with neutral point and one without neutral point).
• 4 Switches 3 positions.
• 1 Switch 2 positions.
• 1 Momentary switch.

Other features:

• System "Model Match" (with X8R receivers): pausing a model, only the selected model on the screen responds to the orders of the radio controller.
• 128x64 LCD display
• All sleeves, sliders, potentiometers and switches can be freely affected
• 60 model memories
• Internal HF module with telemetry capable of transmitting up to 16 channels with a refresh rate of 9ms
• Location for external HF module ( JR module format).
• 3 screens for displaying customizable telemetry, data log (requires micro SD card)
• 64 free mixes, activatable per flight phase group
• 16 customizable curves of 3 to 17 points each
• 32 logic switches
• Multimode transmitter (1-4)
• Compatible telemetry "Smart Port"
• Standard JR (jack) plug capable of receiving up to 8 channels and sending up to 16 channels.
• Audio jack for plugging in headphones (telemetry voice announcement)
• Mini USB jack to connect the transmitter to the PC (firmware update, backup configuration restore and model memories)
• Integrated vibrator

The difference between this radio and the Fr-sky Taranis X9D radio:

• Lower price
• Slightly smaller screen and simplified display.
• Fewer switches and proportional channel controls.
• Delivered without microSD card

The difference between this radio and the X9Lite fr-sky radios:

• Comes with a strap.
• Features an additional switch.
• Includes an additional potentiometer.

Delivery:

• Transmitter FRSKY Taranis Q X7S ACCESS ACCST with emission firmware EU-LBT Version v2.1.x, blue color.
• A neck strap
• USB cable
• Notice TECNIMODEL in French

Necessary material not provided:

• 2 Li-Ion batteries format 18650

Choice of receivers

This radio controller can be used with the receivers proposed in the "accessories" section. The receiver must be EU-LBT Version v2.1.x. Each sink must be associated in a model memory.

1 X8R receiver EU-LBT allows to use 8 channels and have telemetry feedback.
2 X8R EU-LBT receivers allow the use of 16 channels.
1 X6R EU-LBT receiver (6 channels plus telemetry)
1 X4R receiver EU-LBT ( 4 channels + telemetry )

Number of channels possible with this radio controller:

• 8-way with an X8R receiver.
• 16 channels by combining sets 2 X8R receivers.
• 24 channels by adding an external transmission module XJT (see "accessories") and combining a total of 3 X8R receivers.
• 32 channels by adding an external transmission module XJT (see "accessories") and combining a total of 4 X8R receivers.

Version information

Taranis QX7 Firmware EU-LBT ACCESS ACCST Version v2.1.x

Firmware OpenTX English/French

Attention: the receivers used must have the EU-LBT firmware: if you already have receivers, you must plan to flash their firmware with the new EU-LBT version to be able to use them with this version of the radio controller.
