LESU Low-profile digital servo with metal gears 10kg/7,2V
Manufacturer Lesu
The LESU servomotor is a powerful, fast servo in a low-profile format for use in confined spaces.
The robust metal gearing ensures long servo life.
Ideal for models requiring a compact, powerful servo.
The servo head is compatible with Futaba servo horn.
Features :
- Length: 40.3 mm
- Width: 20 mm
- Height: 28.3 mm
- Speed: 0.18sec/60degree 6V ; 0.15sec/60degree 7.2V
- Torque: 9kg/cm 6V; 10kg/cm 7.2V
- Profile: Low-profile
- Operating voltage : 4.8-7.4Volts
- Weight: 42 g
- Gears: metal
- Cable length: 20cm
- Connector type: Graupner/JR
- 25T output
Warning! It is not possible to use a 2s lithium battery as a direct power supply, as the voltage of the charged battery will fry the servo.
For 7.4V operation, a U-BEC or voltage regulator is required to produce a stabilized voltage of 7.4v.
