Tamiya RC Tipper Truck Mercedes Arocs 3348 Italian Red Edition 56361

Tamiya RC Truck Mercedes Arocs 3348 Tipper 6x4

Tamiya 56361

Radio controlled dump truck, kit to assemble, on a 1/14th scale

Version delivered with body painted in red TS-8 and bucket painted in shiny aluminum TS-17.

Discover the assembly of this truck on our blog.

It can be equipped with the optional module "MFU" (ref Tamiya 56523) which allows the operation of lighting, sound and integrates a vibrator to simulate the vibrations of the engine as well as a variable speed.

The kit features a realistic 3-axle chassis equipped with suspensions, a 3-speed gearbox and a very faithfully detailed cab. The chassis elements (tanks, exhaust , platform, etc... are faithfully reproduced. The majority of the body details are also reproduced, bringing a remarkable realism of the model, such as retros, foot steps, logos, grille, headlights, etc...

This model can be equipped with a lifting system (available separately) electrically operated.

Description of the model:

• Chassis three axles. Transmission to the four rear wheels.
• Ladder frame chassis features aluminum profiles and plastic cross-members.
• New metal Tipper chassis.
• Sturdy ABS Tipper molded in one piece with movable flap attached.
• New 35T TR Mighty Tuned engine providing enough power to carry a maximum load of 10kg.
• 3-speed transmission controlled from the transmitter
• Tires and rear fenders specific to this model. New rear lights.
• Front & rear suspension with leaf springs and spring shock absorbers
• Floating front axle and suspended rear axles with differentials
• Compatible with the Multi-Function Unit MFC-03 (ref.56523) or MFC-01 (ref.56511) sold separately, for light effects and realistic sound.
• Requires the RC ELECTRIC ACTUATOR SET ref.56545 (sold separately, see "accessories on this page") to control the Tipper from the transmitter.
• See loading restrictions in the package leaflet.
• Body parts painted in Italian red TS-8.
• Tipper parts painted in Shiny Aluminum TS-17.
• These pieces are then covered with polyurethane varnish for a glossy and durable finish.

Equipment to be acquired separately:

• RC ELECTRIC ACTUATOR SET for dump feature of the tipper body (Tamiya 56545)

• Minimum 4-way radio controller

• Battery 7,2v

• electronic Speed Controller ( Or Tamiya Multi-Function Unit)

• 2 Servos

• Battery charger and charging cords
