RoMarin by Krick ro1000

Krick decided to re-edit this Robbe old construction kit, seduced by the elegant, slender shape of its hull and the harmonious structure of the vessel, which also offers numerous customization possibilities, from coastguard boats of all kinds to an elegant classic motor yacht.

This tall, slender hull offers numerous possibilities for special functions such as lighting and crane operation.

Key features:

• Hull and deck with coaming, deflector and chimney in thermoformed ABS
• Transparent superstructure with marked windows and doors and laser-cut window masks
• Precision laser-cut wood and plastic parts for motors installation and all superstructure parts
• 2-shaft propulsion with 3-blade propellers
• 2-rudder steering
• Injection-molded mast with details and space inside for wiring
• Rail stanchions laser-cut railings and portholes
• Detailed windlass and other fittings manufactured in high-quality 3D resin printing
• ABS accessories, dinghy and spare parts
• Detailed assembly instructions and construction plan (German only at present)

Technical specifications :

• Length: 915mm
• Width: 180mm
• Height: approx. 500mm
• Draft: approx. 70mm
• Displacement: 3.5kg

Information about the actual boat:

Until 2000, the police boat W-3 belonged to the Lower Saxony river police fleet and was stationed in the outer harbor of Emden.
The vessel was built at the Gebr.Schürenstedt shipyard in Bardenfleth. It was mainly used to monitor and secure coastal shipping, particularly at the entrance to Emden harbor.
In 2000, the ship was decommissioned and replaced by a new vessel, also named W-3. The old vessel is now in private ownership.

Technical specifications of the original :

• Overall length: 22.50m
• Beam: 4.30m
• Draught: 1.49m
• Displacement: 49.3t
• Height above water: 9.60m

Equipment sold separately (in accessories below):

• 2-channel radio set minimum
• Steering servo
• Propulsion motors
• Propulsion ESC(s) or controllers
• 7.2V NiMh battery
• Paint, glue, cables, connectors, etc. are also required

Motorization options :

- Brush motor :

• 2 MAX Gear Motor 2.5:1 ref: MOKR42275
• Interference suppression ref: ACTM00002
• 2 Rigid couplings Ø4mm/Ø6mm ref: ACMP53033

• 1 ESC Quicrun 0880 for controlling the 2 shaft lines together ref: VAHW30120301
• OR
• 2 Quicrun1060 variable speed drives for controlling the 2 shaft lines separately ref: VAHW30120201

• 2 pairs of motor leads ref: ACAV612824

- Brushless motors :

• 2 Max Marine P365 550KV brushless motors ref: MOKR42437
• 2 Rigid couplings Ø5mm / Ø4mm ref: PBRO1450
• 2 Brushless controller HobbyWing Seaking 60A réf : VAHW30302200
