FlySky Paladin PL18 EV Ultimate Edition 18-channels

PALADIN PL18 EV Ultimate Edition

Made by FlySky

PALADIN PL18 EV Ultimate Edition kit, with aluminum case, 2 receivers, induction charger, aluminum console, harness and USB cable.

The PALADIN PL18EV is a new model of radio control from FLYSKY, featuring a touchscreen and 2 "5D" handles, making it particularly suitable for piloting radio-controlled models of construction machinery. This version comes complete in a large aluminum case, with harness and CNC-machined aluminum console (to be fitted), induction charger, 2 receivers and various other accessories.

The radio control includes 2 "5D" control sticks, 2 mini proportional control sticks with neutral return, 3 potentiometers and 8 switches.

The "5D" handles, for each handle :

• 2 conventional channels (cross handle)
• 1 proportional channel on stick rotation
• 2 pushbuttons on the top of the stick

Switches are distributed as follows

• 1 impulse 2-position switch
• 3 impulse 3-position switches
• 1 2-position switch
• 1 3-position switch
• 2 pushbuttons

Contents :

• Paladin PL18EV FLYSKY 18-channels radio control system with built-in Lipo battery
• Aluminium carrying case
• 2 receivers: 1x FGr8B and 1x FGr12B
• Induction charging base (wireless charging): requires USB phone charger (not included)
• USB cable
• Aluminum stand (for assembly)
• Textile harness and aluminum back brace
• Decorative sticker sheet

Instructions in English only (see download).

Features :

• Aluminum handles on hall-effect potentiometers
• Aluminum side handles with neutral return, controllable from above or below
• Touch screen
• Number of channels: 18
• Model type: Construction machine model / Truck model / Military vehicle model / Special vehicle and ship model / Robot model
• Number of memories: 20
• RF: 2.4G
• RF power: <20dBm
• Protocol 2.4GHz : AFHDS3
• Range: >500M (ground range)
• Channel resolution: 4096
• Battery: 1S (3.7V) * 4300mAh (integrated)
• Charging interface: Micro USB / wireless charging
• Charging time: 4h@5V*2A / 7h@5V*2A (wireless charging)
• Operating time: >5h30
• Low voltage warning: <3.65V
• Antenna type: Dual antenna
• Display: HVGA 3.5" TFT, 320*480
• Language: Chinese and English
• Simulator: USB simulator
• Data interface : USB, non-standard interface (USART), PHJACK (PPM)
• Temperature range: -15°C to +60°C
• Humidity range: 20% - 95
• Online update: support
• Transmitter color: Black
• Dimensions (length x width x height): 214*120*196mm
• Body weight: 1012g
• CE certification, FCC ID: N4ZFT1800

Compatible receivers :

All FLYSKY receivers using the AFHDS3 protocol:

• FTr4 4-channel receiver
• 8-channel receiver FTr8B
• FTr12B 12-channel receiver
• 16-channel S.BUS receiver FTr16S
• 8-channel receiver FGr8B
• 12-channel receiver FGr12B
